Bottle blowing machine consists of 1 plastic preform tipper

1. Bottle blowing machine consists of 1 plastic preform tipper: pour the plastic preform into the plastic preform funnel through the elevator

2.  The plastic preform hopper stores the plastic preform to ensure continuous preform supply to the blow molding machine

3.  The plastic billet is transported upward through the conveyor belt

4.  Plastic preform finisher: the plastic preform is arranged into the preform with the mouth facing up by the roller and coexists on the conveyor line, and the surplus preform is recycled into the plastic preform buffer bucket through the conveyor belt

5.  Plastic blank supply track: the bottle blank detector uses the detected plastic blank mouth to supply the processed plastic blank to the imported starwheel of the linear heating module, and the vacuum ion purging machine is used to purge the inside of the plastic blank

6.  Imported star wheel: heating mandrel of linear heating module, plastic billet supply star wheel will supply plastic billet with heating mandrel

7.  Linear heating module: when the plastic billet passes through the heating area, it is heated to 90-115 ℃

8.  Heating mandrel chain: plastic billet gripper, used to grab the plastic billet and heat it in the heating furnace.  The mandrel chain drives the heating mandrel to rotate to ensure uniform heating of the plastic billet

9.  Heater

10.  Imported starwheel blow molding wheel

11.  Export starwheel blow molding wheel

12.  Blow molding wheel

13.  Blow molding station

14.  Exit starwheel

15.  Switch cabinet

16.  Ice water supply

17.  Air supply

18.  Water cooling ice water unit
